BOD Incubator
Introduction
A BOD (Bio Oxygen Demand) incubator is an essential laboratory equipment designed for the incubation and preservation of biological samples under controlled environmental conditions. At Kesar, as a reliable BOD incubator manufacturer, we engineered this device to provide precise temperature control, creating optimal conditions for the growth and observation of microorganisms in water, waste water samples and test tissue culture growth. Our BOD incubators are crafted with advanced technology, ensuring accurate and stable incubation environments for Pharmaceuticals, Laboratories, Chemicals, Life Science, Government Institutes, and Cosmetics etc.
Construction
- Constructed and fabricated on fully automatic CNC machines.
- Corrosion-resistant High-Grade stainless steel in Inner and Outer or powder-coated mild steel exterior ensures long-lasting performance.
- Stainless steel inner chamber with smooth surfaces allows easy cleaning and prevents contamination.
- High-density PUF (Polyurethane Foam) insulation minimizes heat loss and improves energy efficiency.
- Adjustable stainless steel shelves provide flexibility for different sample sizes.
- Silicone gasket-sealed door ensures a tight closure, reducing temperature fluctuations.
- Transparent inner glass door allows observation without disturbing internal conditions.
Technical Specification
| Temperature Range | 10℃ to 60℃ |
|---|---|
| Accuracy | ±1.0℃ |
| Uniformity | ±2.0℃ |
| Control System | PLC or PID Based |
Material of Construction
| Models | Material Of Construction | |
|---|---|---|
| Interior | Exterior | |
| STD | S.S.304 Dull Finish | G.I Powder Coated |
| GMP | S.S.304 Dull Finish | S.S.304 Dull Finish |
| CGMP | S.S.316 Dull Finish | S.S.304 Dull Finish |
Sizes
| Models | Capacity | Dimensions (W X D X H) | Max No. of Trays | |
|---|---|---|---|---|
| Internal Width x Depth x Height (mm) |
External Width x Depth x Height (mm) |
|||
| KGOB-90 | 90 LTR | 450 X 450 X 450 | 600 X 920 X 1060 | 2 |
| KGOB-227 | 227 LTR | 600 X 630 X 600 | 750 X 1100 X 1210 | 3 |
| KGOB-325 | 325 LTR | 600 X 630 X 900 | 750 X 1100 X 1510 | 5 |
| KGOB-400 | 400 LTR | 600 X 630 X 1060 | 750 X 1100 X 1670 | 6 |
| KGOB-500 | 500 LTR | 600 X 630 X 1330 | 750 X 1100 X 1940 | 8 |
| KGOB-600 | 600 LTR | 800 X 800 X 950 | 950 X 1270 X 1560 | 5 |
| KGOB-800 | 800 LTR | 800 X 800 X 1250 | 950 X 1270 X 1860 | 7 |
| KGOB-1000 | 1000 LTR | 800 X 800 X 1570 | 950 X 1270 X 2180 | 10 |
Other Details
Specifications
BOD (Biological Oxygen Demand) Incubator is a reliable device that ensures incubation of cultures under completely artificial control and completely insulated from harsh external environments.
Control Systems
Advanced control system ensures precise temperature regulation and user-friendly operation.
7” HMI/PLC Digital display shows real-time temperature readings for easy monitoring.
The auto-tuning system automatically adjusts temperature fluctuations for consistent performance.
Safety alarm system alerts users in case of temperature deviations.
Programmable settings allow users to set temperature cycles for different incubation requirements.
User-friendly interface with simple push-button controls and an LED display for easy operation.
Overheat protection with built-in safety mechanisms to prevent excessive heating.
Low-noise operation ensures a quiet laboratory environment.
Energy-efficient cooling system minimizes power consumption while maintaining stable temperatures.
Powerful air circulation system ensures uniform temperature distribution inside the chamber.
Get Solution
Contact Kesar Control today to learn more about their Products and get a quote.
Contact NowDownload Catalogue
Features
- Heavy duty stainless steel construction
- Illuminated interior.
- Multi-pane viewing door prevents condensation to ensure a proper view.
- Heavy-duty solid stainless steel duly electro polished perforated/Wire mesh type trays which are easy to clean and adjustable.
- PLC or PID based Control panel with electrical switchgear and refrigeration system mounted on top for easy service accessibility.
Safety & Alarm Features
- Password protected door access.
- Temperature deviation alarm.
- Power Failure Alarm.
- Continues open door alarm.
- Extreme temperature prevention cut-off system.
- Auto change over Facility for Refrigeration System.
- Door hinges and latches are durable and of high quality to ensure a perfectly uniform seal in the long term.
- Inner and outer doors are completely sealed by silicone rubber gaskets for maximum efficacy.
Optional Features
- Stand-by refrigeration system.
- Scanner.
- GSM Alert System.
- Security Alarm System.
- Microprocessor based PID controller with auto tuning for accurate control of temperature conditions.
- Pt100 Sensor for Temperature Control.
- Data Storage unit facility to store data and to print directly on printer or transfer to software with Date, Time, SV, PV, Door Open/ Close, Power On/Off remarks.
- Safety: Temperature High / Low Alarm, Temperature very High / Low cut off.
- 7″ HMI with TFT LCD Colour touch screen with password protection for all parameter actual status monitoring of utilities like Sensor, Heating & Cooling System.
- Pt100 Sensor for Temperature Control for better accuracy.
- PLC with auto tuning facility for accurate control of temperature conditions.
- PLC system for an auto changeover of standby systems.
- Data Storage unit facility to transfer the data to software via Ethernet for web based online remote monitoring with Date, Time, SV, PV, Door Open/ Close, Power On/Off remarks. Also transfer the data through USB.
- Safety/Alert: Temperature & Humidity High / Low alarm, Temperature & Humidity High / Low cut off, Low water level cut off, Auto change over for standby systems
FAQ'S
A BOD (Biochemical/Biological Oxygen Demand) incubator is laboratory equipment that maintains a precise, stable temperature to incubate biological samples, most commonly water and wastewater samples for BOD testing, as well as microbial cultures and tissue samples, under controlled conditions isolated from external environmental fluctuation.
BOD (Biochemical Oxygen Demand) testing measures the amount of dissolved oxygen microorganisms consume while breaking down organic matter in a water or wastewater sample, typically over a standardized 5-day incubation period at a fixed temperature (commonly 20°C). Even small temperature drift changes microbial activity rates, which is why incubator accuracy directly affects whether a test result is valid.
A BOD incubator is optimized for water/wastewater BOD testing and general sample incubation, typically operating from 10°C to 60°C. A bacteriological incubator is built specifically for bacterial culture growth and, in advanced models, adds humidity and CO₂ control alongside temperature, a feature set BOD incubators don't include.
Check the temperature range and accuracy against your test protocol (±1.0°C is standard for BOD work), stainless steel interior construction for corrosion resistance, data logging capability for accreditation records, NABL-traceable calibration, and door/temperature deviation alarms. These determine whether the incubator's output will hold up under NABL lab accreditation audits.
Kesar Control's BOD incubator operates from 10°C to 60°C with ±1.0°C accuracy and ±2.0°C uniformity, using PLC or PID-based control depending on the model.
The BOD incubator is available from 90 litres to 1,000 litres across the KGOB series, with tray capacity from 2 to 10 trays, and STD, GMP, or cGMP material of construction options for different regulatory environments.
The BOD incubator includes password-protected door access, a temperature deviation alarm, power failure alarm, continuous open-door alarm, extreme temperature cut-off protection, and automatic changeover for the refrigeration system on PLC-based models.
Yes. Both the PID and PLC control options store temperature data with date, time, setpoint, process value, and door open/close events, either printed directly or transferred via USB or Ethernet, supporting NABL lab accreditation and audit documentation requirements.
